ODP-ACEDINC

SAE Metric

Dimensions

Length	20.4 in
Width	10.8 in
Height (terminals included)	9.5 in
Weight	143 lbs

Specifications

Voltage

12

Pulse (5 second) Hot Cranking Amps (PHCA)

2300

Cold Cranking Amps (CCA)

1250

HCA

1750

MCA

1500

20Hr Nominal Capacity (Ah)

215

10Hr Nominal Capacity (Ah)

190

Reserve Capacity Minutes

450

Terminal

SAE

Torque Spec in-lbs (Nm max)

-

Internal Resistance (mΩ)

2.7

Short Circuit (A)

4600

Recommended Min. Charging Current (A)

19

Operating Temperature Range

-40°F / -40°C to 149°F / +65°C

Optimum Storage Temperature

68°F / +20°C
